Fabtech 8-inch lift kit designed for 2008–2010 Ford F250 4WD trucks without factory overload springs. Features a robust 4-link rear suspension system, adjustable 4.0 coilover front shocks, and rear dual-mode DLS shocks for enhanced off-road performance and on-road comfort.

Description

At the top of our Super Duty line is our famous 4 Link System that provides unsurpassed articulation and wheel travel. Large 2” diameter heavy wall links feature race style 1” Uniballs for superior strength. Thick 1/4” steel brackets secure the 4 Links to the frame without cutting or welding. This 4 Link system includes our Dirt Logic 4.0 Stainless Coilover Shock conversion. The system also includes Sway Bar drops, Trac Bar relocation bracket, Pitman Arm, rear Add-a-leafs, and a Block & U-bolt kit. Includes rear 2.25 Dirt Logic Stainless Steel shocks.
TIRE SIZE – 37/13.50R20 WHEEL – 20X10 W/4 1/2″ BS W/MINOR TRIMMING; TIRE SIZE – 355/65R18 WHEEL – 18X9.5 W/4 3/4″ BS W/MINOR TRIMMING; 27. FRONT DRIVE SHAFT MODIFICATION MAY BE REQUIRED TO CLEAR EXHAUST ON GAS MOTOR.

Fitment:
2008 Ford F-250 Super Duty
2008 Ford F-350 Super Duty
2009 Ford F-250 Super Duty
2010 Ford F-250 Super Duty
