Aluminum Cylinder Heads For Small Block Ford Windsor (289–351) – 203Cc Combustion Chambers

Description

Complete Small Block Ford Windsor 289-351 203cc Aluminium Cylinder Heads with 58cc Chamber (Pair)

2.13″ x 1.28″ Intake Port, 1.40″ x 1.40″ Exhaust Port

AF95-2360

95-2360

Head SpecificationsMaterial: A356 AluminiumChamber Chamber: 58ccIntake Port Volume: 205ccIntake Port Dimension: 2.13″ x 1.28″Exhaust Port Volume: 71ccExhaust Port Dimension: 1.40″ H x 1.40″ WExhaust Port Location: Raised .250″Spark Plug Location: OEMIntake Valve Diameter: 2.08″Exhaust Valve Diameter: 1.60″Valve Stem Diameter: 8mmValve Spring Pocket I.D.: 1.64″Valve Guide Material: Manganese BronzeValve Guide O.D.: .490″ (.560″at base)Rocker Stud Thread Size: 7/16″ x 14Valve Angle: 20°Deck Thickness: .750″
