Description
About this product
The 80cc Engine is a robust 3.0HP solution perfect for small and stationary applications. It’s designed with precision and efficiency in mind, making it ideal for a variety of uses. With a single-cylinder 4-stroke OHV configuration, this engine provides a displacement of 79.4cm3 and a power output of 1.1 kW at 3600 RPM. This model, 152F-3, ensures reliability and performance in delivering up to 3.1 Nm of torque at 3240 RPM.
Featuring a counter-clockwise PTO shaft rotation and a forced air cooling system, this engine is both durable and efficient. Its compact design boasts a dry weight of just 9.2 kg, and it maintains a fuel consumption rate of 450g/kWh, emphasizing its economical operation.
Specifications
| Specification | Detail |
|---|---|
| Model | 152F-3 |
| Type | Single Cylinder 4 Stroke OHV |
| Displacement | 79.4cm3 |
| Bore X Stroke | 52 x 37.4 mm |
| Power Output | 1.1 kW / 3600 RPM |
| Max Torque | 3.1 Nm / 3240 RPM |
| Fuel Consumption | 450 g/kWh |
| Cooling System | Forced air |
| Horsepower | 3.0 HP |
| PTO Shaft Rotation | Counter-clockwise |
| Dry Weight | 9.2 kg |
Features & Benefits
- High performance with 3.0 horsepower.
- Efficient fuel consumption at 450 g/kWh.
- Lightweight design at 9.2 kg.
- Reliable with single-cylinder 4-stroke OHV engine.
- Ideal for stationary and small engine applications.
- Robust build for extended durability.
