Description
About this product
The Wet Clutch 2:1 Reduction Gearbox is ideal for applications ranging from 8HP to 13HP, specifically compatible with GX240 to GX390 engines. This high-quality gearbox is designed with a precision-machined aluminium die-cast housing, ensuring durability and reliable performance. It features a clutch drum equipped with weights, an oil seal, and bearings (E-205 / GB276-82) for optimal functionality. The gearbox also comes with gaskets and an oil dipstick with a breather, enhancing convenience and maintenance ease. The standard SAE mounting hole configuration allows for straightforward installation onto compatible engines.
Specifications
| Specification | Detail |
|---|---|
| Applicatio | 8HP – 13HP (GX240 – GX390) |
| Input Shaft | 25mm Diameter, 60mm Long |
| Input Shaft Keyway | 7mm |
| Input Mounting Holes | 90mm Square |
| Output Shaft | 22mm Diameter, 50mm Long |
| Output Shaft Keyway | 7mm |
| Output Mounting Holes | 70mm Square |
| Bearings | E-205 / GB276-82 |
| Output Mounting Holes Detailed | M8(x4) – 21mm Threaded Deep |
Features & Benefits
- Compatible with a range of GX240 to GX390 engines; suitable for 8HP to 13HP
- Precision-machined housing ensures durability
- Standard SAE mounting configuration for easy installatio
- Clutch drum with weights for smooth operatio
- Includes oil seal, gaskets, and dipstick with breather
